Ventus | VTB Aetos Max Controller
Regular price
$1,199.00 Regular price Sold out Unit priceBike-specific harness sold separately from the controller. Ventus V9600 Wiring Harness
Ventus Aetos Max Specs
- Rated Voltage 96V (20s) (Breakdown @ 138V)
- Phase Current 860A (1300A Tested)
- Battery Series (12s-26s)
Transform your E-moto into a true racing machine with the VTB V9600 Gen.2 smart controller.
Built for riders who demand precision and power, the V9600 Gen.2 is one of the most advanced controllers available today. Capable of delivering up to 76 kW, it gives you full control over motor behavior through a detailed, intuitive mobile app. Whether you're unlocking maximum output or fine-tuning throttle response down to the smallest detail, the V9600 Gen.2 stays smooth, progressive, and perfectly manageable—while still delivering explosive acceleration when you want it.
Compatible with the Sur-Ron Light Bee, Sur-Ron Ultra Bee, Talaria Sting, and Eride PRO, this controller completely transforms your e-moto: instant response, customizable ride profiles, intelligent regenerative braking, and next-level adjustability. It’s a true upgrade for riders who want to extract 100% of their machine’s potential.
Future updates will unlock even more advanced features, including wheelie assist, anti-rollover support, G-force tracking, and high-precision electronic fall detection.
TECH SPECS
Voltage
- 120V (Breakdown@ 138V)
- Rated Voltage 96V
Phase Current
960A (Tested to 1300A)
Battery Series
12s - 26s
Power
76kW
MOSFET
30x high-performance MOSFETs
Performance Enhancement vs Gen 1
- Thermal Dissipation Capacity: ↑ 28.2%
- Temperature Rise Reduction: ↓ 18%
- Overcurrent Capability: ↑25%
Vibration Performance
High-resilience silicone potting process that can meet ISO vibration testing
Operating Performance
-30 to 80°C
Waterproof Rating
IP67+
Heat Sink Structure
New CNC heat sink, with thickened heat sink options available
Features
- Safety-Isolated Power Architecture: 1500V reinforced insulation between battery/throttle interface
- BMS connect via Bluetooth: Real-time SOC/temperature monitoring & dynamic power limiting
- Robust I/O Circuit Protection: Capable of withstanding prolonged high-voltage surges & short-circuit anomalies
- High-Performance Throttle Sensing: 1000 Sa/s sampling rate & 0.0034V resolution
- Compatible with 13 different types of bikes, 68 different types of batteries & 34 different types of motors
- Plug & Play System: Complete wiring harness & mounting kit. Intuitive graphical App with one-tough auto-configuration
- Built-in IMU: Future updates will unlock advanced features including anti-rollover support, cornering G-force tracking & high-precision electronic tip-over protection
PRODUCT BROCHURE | WARRANTY
WARRANTY --- 2 years | Replacement-only policy for MOSFET failure
- Tradewind Detour - Any warranty issues/repairs, we can help!
Ventus | VTB Aetos | Max Controller
ADVANCED FEATURES
Maximum Power
- Engineered for peak performance, the AETOS V9600 Gen.2 handles up to 1200A of motor phase current with power spikes reaching 76 kW
- Its upgraded electronic architecture delivers rock-solid stability and instant acceleration even under full load.
Reinforced Insulation Power Architecture
- 1500V isolation between the battery and throttle circuitry for maximum electrical safety.
High-Precision Throttle Sensor
- Features a 1000 Sa/s sampling rate with 0.0034 V resolution, giving you ultra-smooth, highly accurate throttle control.
Robust I/O Circuit Protection
- Built to withstand sustained high-voltage surges and short-circuit events without performance loss.
Optimized Thermal Efficiency
- A redesigned thermal system provides 28.2% better cooling and runs 18% cooler than the Gen.1 controller. This means better reliability, longer endurance, and consistent performance in extreme conditions.
Ultra-Precise Tuning & Control
- Fully customize your bike to your riding style with adjustable:
- Throttle response
- Dead zones
- Power curves
- Burst mode
- High-speed compensation
- Speed limits
The dedicated mobile app delivers clear, intuitive real-time tuning.
Integrated IMU (Inertial Measurement Unit)
- Future firmware updates will unlock advanced features such as:
- Wheelie assist
- Anti-rollover protection
- G-force tracking in corners
- High-precision electronic fall detection
Multi-Driving Modes
- Switch instantly between riding profiles with 5 programmable modes. Adjust power and throttle feel on the fly using the handlebar controls — ideal for changing terrain and conditions.
Smart Regenerative Braking
- Five levels of adjustable engine braking, recovering up to 30% energy. Can also be controlled with a thumb brake for precise modulation while descending or cornering.
Mobile App (iOS & Android)
- Built-in Bluetooth lets you tune settings straight from your phone. Fully compatible with BMS systems and smart dashboards for seamless ecosystem integration.
High-Resolution Color Display
- The HD screen provides live feedback on power, temperature, voltage, speed, battery status, and more. ANT-BMS communication allows charging data to appear simultaneously on the dash and app.
Built for Durability
- A CNC-machined aluminum body with an optimized heat sink and IP67 water/dust protection ensures long-term reliability in harsh environments.
Integrated Security System
- Features contactless unlocking with redundant safety layers. Unlock the bike using a PIN code or automatically via Bluetooth pairing with your smartphone.
COMPATIBILITY
The VTB V9600 controller is built for maximum flexibility, with wide compatibility across bikes, motors, and battery systems. Whether you’re running an OEM setup or a full custom build, the V9600 adapts seamlessly to high-performance configurations.
Compatible E-Motos (13+)
- Sur-Ron Light Bee
- Sur-Ron Ultra Bee
- Talaria Sting (MX3 / MX4 / MX5)
- 79 Bike Falcon
- Eride Pro SS / SR
- Ventus One / One+
- And additional models supported through harness updates
Compatible Motors (34+)
VTB Motors:
- Beast 28 kW
- Beast 35 kW
- Ryuga 52 kW
- Ryuga 81 kW
OEM Motors:
- Sur-Ron Light Bee
- Sur-Ron Ultra Bee
- Talaria Sting
- 79 Bike Falcon
Aftermarket Motors:
- QS165
- LTXS
- Sotion FW01 (LB & Talaria)
- KO Moto
- EBMX XLB-60
- EBMX XUB-80
Compatible Batteries (68+)
- Wide voltage support: 36V to 135V (12S to 32S)
- Fully compatible with OEM Sur-Ron batteries
- Supports most upgraded and high-performance battery packs
- Works seamlessly with both standard and high-output BMS systems
INCLUDED IN THE BOX
1× VTB V9600 AETOS Controller
1× High-Resolution Color Dashboard
- Crystal-clear real-time display of power, speed, temperature, voltage, and system data.
1× Dashboard Mount
- Sturdy, adjustable mount for optimal screen positioning and visibility.
1× Switch Assembly
- Quick, intuitive control of riding modes and on-the-fly adjustments.
1× Thumb Regenerative Brake Lever
- Precise modulation of regen braking with instant energy recovery on demand.
⚠️ Important Notice ⚠️
This product is intended strictly for private tracks and closed-course riding.
It is not street-legal and must not be used on public roads
